Power Rackmount Workstation PRW-XL

SKU:

G090PRW-XL

No matter where you are in your decision making process.
We are ready to help you!

Schedule a 15-minute consultation call.

Power Rackmount Workstation PRW-XL

High-performance 4U rackmount workstation powered by Intel® 15th Gen processors, supporting NVIDIA RTX graphics, DDR5 memory, and advanced security features.

Key Benefits:

Enterprise-Grade Performance – Powered by Intel® 15th Gen processors and DDR5 6400 MHz memory, supporting up to 256 GB for high-intensity workloads.
Professional Graphics Capability – Supports NVIDIA RTX A1000 to A6000 GPUs for advanced 3D, animation, and video rendering applications.
Flexible Storage & Expansion – Multiple Gen5 and Gen4 M.2 slots, SATA options, and optional removable drives for fast, scalable storage.
Secure & Manageable – Features TPM 2.0, Secure Boot, vPro Enterprise, and remote hot-swap capability for enhanced IT control.
Versatile Connectivity – Multiple DisplayPort 1.4 and HDMI 2.1 outputs, plus configurable copper or fiber network ports for flexible deployment.

Technical Specs

CPU / Processor

Intel15th Gen
• U9 285K (24C/24T, 3.7 GHz up to 5.7 GHz, 125W) vPro
Enterpri
se, TPM 2.0, Secure Boot
• U9 285 (24C/24T, 2.5 GHz up to 5.6 GHz, 65W) vPro
Enterpri
se, TPM 2.0, Secure Boot

Video

NVIDIA RTX Pro Blackwell 6000 Max Q, 5000, Ada 4000, A1000

GPU

Single Slot No Power: 75W – A1000
Single Slot with Power: 150W – RTX A4000 Ada
Double Wide: 300W – RTX A6000 Max Q

External Ports

2 x DP 1.4 (MB)
1 x HDMI 2.1 (MB)
4 x DP 1.4a (RTX 6000, 5000, 4000)
4 x mDP (RTX A1000)
3 x Rear Audio Ports (Line-In/Line-Out/Mic-In)
1 x USB 3.2 Gen 1 (Type C)
2 x USB 3.2 Gen 1 (Type A)
1 x USB 3.1 (Type A)
4 x USB 2.0 (Type A)
1 x 1 Gigabit LAN
WiFi Available
1 x PS/2 Keyboard
1 x PS/2 Mouse

Internal Ports

USB Header

1 x M-Key 2242/2260/2280 (Gen5)

1 x M-Key 2242/2260/2280 (Gen4)

1 x E-Key 2230

4 x SATA

1 x PCIe 5.0 x16

1 x PCIe 4.0 x16 (x4 electrical)

1 x PCIe 4.0 x1

Network

1 x 1 Gigabit LAN

Memory

DDR5 6400 MHz
Recommended: 128GB
Max: 256 GB (CUDIMM)/192(DIMM)

Storage

1 x M-Key 2242/2260/2280 (Gen5)
1 x M-Key 2242/2260/2280 (Gen4)
1 x E-Key 2230 (via Innodisk A+E key storage)
4 x SATA 2.5”
Optional SATA 2.5” removable (1 x rear removable)

Operating System

Stratodesk NoTouch OS
Windows 11 Pro
Linux

Dimensions

7” (H) x 16.54” (L) x 19” (W)
Rack U: 4U
Density:4U (17” deep)

Rack Density

Other
